Foodstuff Transfer Hose Type:FXN10/FXU10 Manufacturer

Foodstuff Transfer Hose Type:FXN10/FXU10

Request a Quote

View All: http://tech-flexcn.com/1-1-1-foodstuff-transfer-hose.html

The foodstuff transfer hose features a negative pressure resistance design. It is applied for the suction and discharging of liquids such as milk, beer, oil, etc. The foodstuff transfer hose is widely used as vent line ( not compressed line) less than 120℃ in food processing and canning workshops, etc. The inner tube is food grade rubber that is free from odors and best fit for food and beverage applications.

Advantages:

White smooth food grade inner tube with effective bacterial growth prevention.
Extra flexibility.
Anti-twist, abrasive and microbial resistance, anti-aging seamless rubber.
Steam sterilizing or using detergent under +130℃.

Construction:

Tube: FDA white NBR rubber, oil resistant with smooth inner surface, 100% non-plasticizer (chemical name: phthalate);
Reinforcement: Multiple plies of polyester tire cord;
Cover: Blue NBR rubber, oil resistant, abrasive resistant, weather-proof, anti-aging, and covered with surface texture;
Temperature Range: -30℃~+100℃（Max. 20 minutes in steam temperature <130℃）
Applicable Standards: FDA 21 CFR 177.2600；LFGB standard；GB 31604-2016

Technical Parameters:

Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	W.P.		B.P.		Safety factor	MBR (mm)	Weight (Kg/m)	N.P. (Kpa)
Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	(bar)	(psi)	(bar)	(psi)	Safety factor	MBR (mm)	Weight (Kg/m)	N.P. (Kpa)
FXN/FXU10-25	1	25	36	10	150	30	450	3	80	0.7	-90
FXN/FXU10-32	1 1/4	32	43	10	150	30	450	3	100	0.82	-90
FXN/FXU10-38	1 1/2	38	49	10	150	30	450	3	115	1.14	-90
FXN/FXU10-51	2	51	63	10	150	30	450	3	150	1.79	-90
FXN/FXU10-64	2 1/2	64	75	10	150	30	450	3	180	2.17	-90
FXN/FXU10-76	3	76	90	10	150	30	450	3	225	3.03	-90
FXN/FXU10-102	4	102	114	10	150	30	450	3	250	3.67	-90
FXN/FXU10-127	5	127	146	10	150	30	450	3	450	6.05	-90
FXN/FXU10-152	6	152	172	10	150	30	450	3	530	7.02	-90
