Kevlar Mesh
The Kevlar mesh consists of high-strength Kevlar fiber cloth, Kevlar fiber mesh and PTFE coating, used for drying, textile, printing and dyeing, baking, packaging, electricity and other industries. The Kevlar mesh features even fibers, high tensile strength, straight warps and wefts. The PTFE coating layer has high purity, thick coating film, outstanding adhesion resistance, good corrosion resistance, easy cleaning and delicate processing technology.
- PTFE coating film features high purity, thick and even coating film, excellent adhesion resistance and high tensile strength.
- Highly polished. Easy to clean. Non-toxic. Corrosion resistant.
- Continuous working temperature range: -70℃~+200℃
- Good electrical insulation properties
- High strength, stable dimension and not easy to deform
- Stable running and no deviation
- Textile finished products drying and conveying.
- Heat shrinkage packaging machine.
- Vegetables and fruits dryer.
- Automatic sealing machine.
- Filtering mesh.
| Fiber type | High strength Kevlar fiber |
| Mesh dimensions | 2mm*4mm |
| Thickness | 0.8mm |
| Weight | 280g/m² |
| Standard breadth | 3.35m |
| Standard length | 100m |
| Elongation | ＜2% |
| Operating temperature | -70℃~200℃ |
| Tensile strength | 1400N/cm |
*Notes:
Keep the temperature below 500℉/260℃;
Don't use knife or sharp objects to clean the glass fabric.
Do not fold or crush.
Cleaning and storage method
Washing with clean water
Drying with towels or tissue.
Rolling or laying flat for storage.
Packaging of different specifications can be provided upon customer's requirements.
