Traditional Chinese Medicine Pill Machine (for Small Pills)

Request a Quote

Website: https://pharma-equips.com/1-2-traditional-chinese-medicine-pill-machine.html

Choose Your Model

• Model: ZW-40 vertical
  1. Output : 5-40 kg/h
  2. Pill specification : 3, 6, 9 g/pc
  3. Total power : 2.2 kw
  4. Dimension : 950×750×1600 mm
  5. Machine weight : 400 kg
• Model: WZ—120 horizontal
  1. Output : 60—120kg/h
  2. Pill specification : 3, 6, 9 g/pc
  3. Total power : 4.9kw
  4. Dimension : 1830×810×1700mm
  5. Machine weight : 1000 kg
• Model: WZ—180 horizontal
  1. Output : 120-180 kg/h
  2. Pill specification : 3, 6, 9 g/pc
  3. Total power : 6.5 kw
  4. Dimension : 1950×880×1630 mm
  5. Machine weight : 800kg

View Details

Features

• Designed with PLC control with touch screen HMI (Human Machine Interface), achieving fully automatic production process.
• Produced pills feature high roundness, saving time for pill reshaping.
• The uniformity of pills is over 98%, reducing time for pill sieving.
• The design of rotation function facilitates assembly, disassembly and cleaning.
• The entire machine body is precisely machined, guaranteeing high assembly accuracy, long-lasting operation, stable running and low failure rate.
• Pill knife is specially treated for enhanced durability.
• Variable frequency speed control for drug materials feeding and cutting, providing high reliability.
• Lubrication system has liquid level indicator, and features good leakage resistance and adjustable liquid dripping volume.
• Feeding section is completely made of stainless steel castings in compliance with GMP requirements.
• Rolling brushes are placed at both sides of pill knife to remove drug materials that are attached on the pill knife.
