966 Wheel Loader
Request a Quote
- The 966 wheel loader uses engine from Shanghai Diesel Engine Co., Ltd.
- The KD switch brings optimal efficiency and easy operation of the wheeled loader.
- Our front end loader is installed with dry type axle from MERITOR.
- Reliable ZF gearbox and torque converter.
- Bucket automatic leveling is available.
- The boom comes with position limitation function.
- For high seal performance and optimal reliability, this wheel loader is engineered with combined seal cylinder.
Consulting Products Information
Technical Specification of Wheel Loader:
Model | 966 |
Length×Width×Height(mm) | 8714×2900×3550 |
Rated load (Kg) | 6000 |
Rated bucket capacity(m3) | 3.7 |
Operating weight(Kg) | 19500 |
Diesel engine | ShangChai SC11CB240.1G2B1 |
Rated output(KW) | 174.5 |
Transmission case | ZF |
Gear positions | 4 forward gear, 3 reverse gear |
Max. drawing force(KN) | 180 |
Max. dump clearance(mm) | 3325 |
Dump reach (mm) | 1433 |
Wheel base(mm) | 3300 |
Total cycle time (s) | 10.5 |
Gallery
![](public/propic/4082/b_1-6-wheel-loader-966_0b.jpg)
![](public/propic/4082/b_1-6-wheel-loader-966_02b.jpg)
![](public/propic/4082/b_1-6-wheel-loader-966_03b.jpg)
![](public/propic/4082/b_1-6-wheel-loader-966_04b.jpg)
![](public/propic/4082/b_1-6-wheel-loader-966_05b.jpg)
