With more than 15 years of experience, Universal Machinery provides automated packaging solutions for labels, tags, award ribbons, air fresheners, and other products. Our automatic stringer machines are multifunctional in that they can complete stringing, looping, knotting, punching, and eyeletting to enhance your productivity.

The stringing machine will string a wide range of non-elastic twine (such as cotton, polyester, polished cottons) and elastic, achieving uniform hard knots. Automatic stringers require minor periodic maintenance and deliver high working efficiency up to 80 tags per minute.
Our versatile automatic stringer is able to meet almost every industry requirement.

Working Process

Hole Punching
Stringing
Knotting
Counting
Counting

Automatic Stringer for non-elastic twine

LM-LY3 Tag Stringer (auto feeding, punching, string, looping, knotting)

Speed: 4800-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

LM-LY3-C(Full Automatic Hang Tag Threading Machine)

Speed: 4800-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

LM-LY3-CH(Full Automatic Hang Tag Threading Machine)

The hang tag threading machine is specially designed for stringing ribbon on the hang tags.

Speed: 4800-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

LM-LY3-CS Tag Stringer (auto feeding, punching, string, looping, knotting)
Work on 2 tags with different sizes at the same time

Speed: 3500-4000 pieces/h
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1120*1350*1490mm
Weight: 650KGS

LM-LY3-EL Tag Stringer (auto feeding, string, looping, knotting)

Speed: 80 pieces/min
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

LM-LY3-EL/2 Tag Stringer (auto feeding, punching, eyeleting, string, looping, knotting)

Speed: 4800-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-2.1mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

LM-LY3-P Tag Stringer (auto feeding, stamping, punching, eyeleting, string, looping, knotting)

Speed: 4000-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 60-200mm
Voltage: 110 or 220 volt
Size: 1210*950*1490mm
Weight: 436KGS

Automatic Stringer for elastic twine

TL-LY8 Tag Stringer (auto feeding, stamping, punching, eyeleting, string, looping, knotting)

Speed: 3600-4000 pieces/h
Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

TL-LY8-EL Tag Stringer (auto feeding, string, looping, knotting)

Speed: 3600-4000 pieces/h
Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 80-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*180mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

TL-LY5 Tag Stringer (auto feeding, punching, string, looping, knotting)

Speed: 4800-5000 pieces/h
Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 55-100mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

TL-LY5-U2(Full Automatic Hang Tag Elastic String Knotting Machine)

Speed: 4800-5000 pieces/h
Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 55-100mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

TL-LY8-EL/2 Tag Stringer (auto feeding, punching, eyeleting, string, looping, knotting)

The hang tag elastic string knotting machine is suitable for stringing die-cut hang tags.

Speed: 3600-5000 pieces/h
Non-Elastic Twine Thickness: 0.3-1.2mm
Loop Length: 55-200mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

TL-LY8-U2 Tag Stringer (auto feeding, punching, string, looping, knotting)

Speed: 3600-5000 pieces/h
Elastic Twine Thickness: 0.3-1.5mm
Loop Length: 55-100mm
Tag Size Min.: 20*35mm
Tag Size Max.: 90*150mm
Voltage: 110 or 220 volt
Size: 1020*950*1490mm
Weight: 416KGS

Examples

If you cannot find the specific string machine for your application, please contact us and we will offer customized string machine for your requirement.

Automatic Looper

LM-LY3-K Automatic Looper

Speed: 4800-5000 pieces/h
Twine Thickness: 0.3mm - 2.1mm
Machine Weight: 400KGS
Machine Size: 1020*950*1490mm
Power Supply: 220V, single phase, 50/60HZ
Power: 0.75KW

TL-LY8-K Automatic Looper

Speed: 3600-4000 pieces/h
Non-Elastic Twine Thickness: 0.3mm - 2.1mm
Elastic Twine Thickness: 0.3mm-1.2mm
Machine Weight: 400KGS
Machine Size: 1020*950*1490mm
Power Supply: 220V, single phase, 50/60HZ
Power: 0.75KW
