GYA4200 Asphalt Paver

Request a Quote

View All: http://sinomachhiglobal.com/11-1-asphalt-paver-clps75c.html

Small pavers are widely used for municipal roads, indoor work, small area projects, etc.
Equipped with full hydraulic automatic telescopic screed, paving width 1.8-4.2m stepless adjustable.
The travel drive system adopts the imported hydraulic piston pump, planetary reducer and plunger motor, which has high reliability; the closed control controls the left and right independent drive modes to ensure stable running of the track drive system, flexible steering and convenient transition.

Consulting Products Information

External multi-point propane gas heating device, reliable ignition, fast heating speed and uniform heat distribution, and automatic flame-off function for flameout, improving safety of use.

Technical Specification:

Model	GYA4200
Length×Width×Height (mm):	5500×2050×3415
Total weight (kg):	10500
Engine	Cummins QSB 3.9-C125
Rated output (kw)	93
Basic paving width (mm)	1800
Max. paving width (mm)	4200
Max. paving thickness (mm)	200
Travelling type	Crawler
Travelling speed (km/h)	0-4.5
Paving speed (m/min)	0-20
Hoper capacity (t)	8

Besides the GYA4200 asphalt paver, SINOMACH have many other kinds of heavy construction and engineering equipment for sale.

Gallery

Brief Description

SINOMACH as a reliable heavy equipment company in China, is making construction equipment for road construction and foundation engineering with decades of experience, SINOMACH has been a high quality heavy equipment maker in China and provide construction equipment and engineering vehicle with resonable prices.
