Lathe Chuck

Request a Quote

View All: http://geotec-drill.com/4-drilling-parts/1-5-13-drill-collar-slips.html

The lathe chuck is a kind of solid powerful chuck which is suitable for all kinds of lathes. The lathe chuck can be up to 20 inches and it is used to grip all kinds of round or square machining tools which is suitable for cutting wood and metal. All the lathe chuck’s size and material can be customized according to user needs.

Lathe chuck materials available

Cast iron chuck
Forged steel chuck
Semi steel chuck

Selecting the Correct Type of Chuck

Scroll type manual chuck ( 2-jaw, 3-jaw, 4-jaw, and 6-jaw)
Independ jaw chucks
Combination jaw chuck

Parameters

External chucking	Size	100	110	125	140	160
	A1(BB)	3-38	3-42	3-53	3-53	3-72
	A2(DB)	3-38	3-42	3-53	3-533	3-72
	A3(DB)	38-71	39-77	39-89	47-97	47-116
	A4(DB)	70-100	70-110	75-125	91-140	47-116
	Greatest swing	128	138	157	174	194
	Jaw stroke	15	19	25	25	34
Internal chucking	Size	100	110	125	140	160
	J1	33-66	33-71	37-87	39-89	39-107
	J2	65-94	65-104	73-123	83-132	83-152
