Description

The purlin roll forming line can roll form both C and Z shapes purlins in one forming line, it not just help you to save footprint but also save setup time. JSR Machinery’s purlin roll forming machine can transform C and Z purlins of different sizes ranging from 100mm to 300mm, which can be done in 10 minutes. When transforming different sizes, precision gauges allow for quick auto adjustment.

High precision rollers are capable of rapidly forming 1.5mm to 3.0mm thickness steels at full speed up to 15m/min. Change from C to Z purlin production can be completed within 30 minutes, thus in addition to size change, shape change between C and Z type is also fast and convenient, greatly enhancing the flexibility of production.

Common Profile
  • C purlin: C80-300
    Material: Cold rolled coil,Galvanized coil,Hot rolled coil
    Width: 80-300mm
    Flange: 40-80mm
    Lip: 10-25mm
  • Z purlin: Z100-300
    Material: Cold rolled coil,Galvanized coil,Hot rolled coil
    Width: 100-300mm
    Flange: 40-80mm
    Lip: 10-25mm
Specifications
Machine Specifications
Weight About 9000kgs
Size About 10m × 1.4m × 1.8m (length × width × height)
Color Main color: blue
Warning color: yellow
Suitable Raw Material
Material Galvanized steel coils
Thickness 1.5-3.0mm
Coil width According to products size
Yield strength 235MPa
Main Technical Parameters
Quantity of stations 16-18
Diameter of forming roller shafts 75mm
Roll forming speed 10-15m/min
Production speed 4-6m/min
Forming roller material Gcr15 mold steel, with quench heat treatment
Cutter material CR12 mold steel, with quench heat treatment
Control system PLC and converter
Electric power requirement Main motor power: 15kw
Hydraulic unit motor power: 5.5kw
Electric voltage According to customers requirement
