MH-900 Cut & Fold Machine

MH-900 Cut & Fold Machine
Request a Quote

MH-900 cut & fold machine holds an outstanding performance due to the following features:

  • Compact design.
  • It's easily operated.
  • It contains a label-sliding rail.
  • Die changeovers can cut five kinds of labels.
  • The digital circuit general motor delivers a soft start.
  • The high-performance optoelectronic system can automatically identify labels and stop running when damaged or when no labels feed.
  • Label cutting length is adjustable by different tooling.
  • Magic eye system is optional upon request.
  • Ideal for cutting and folding printed labels and labels.
Specifications
Cutting and folding types 1. End Fold 2. Centre Fold 3. Length Fold 4. Triangle Fold 5. Cut into Slices
Cutting type 1. Cooled shearing 2. Hot cut shearing
Cutting Length 15--160mm
Cutting Width 10--75mm
Cutting Speed 30-200/min
Power Single-phase 220V / 50-60HZ
Consumption 1.8kw
horsepower 1/2Hp
Weight 295KG
Dimensions 1100 x 950 x 1620mm

You can contact us for a quotation or with any questions you may have on this product.
