Small Format CO₂ Laser Cutting Machine
Request a Quote
Specifications
| Model | | | |
| Cutting area | 400*600mm | 900*600mm | 1300*800mm |
| Machine weight | 250kg | 350kg | 420kg |
| Machine dimensions (L*W*H) | 1.2*1*1.1m | 1.5*1.15*1.1m | 1.8*1.5*1.1m |
| Laser power | 60W-180W(customized) | ||
| Positioning accuracy | ±0.01mm | ||
| Min. line width | 0.15-0.3mm | ||
| Total power | < 1600W | ||
| Power supply | 220V/10 50/60HZ | ||
| Control system | High-speed control | ||
| Cooling method | Water cooling | ||
| Control support | Offline control/U disk/color screen/cutting software | ||
| Graphic formats | AI/DXF/BMP/JPG/CAD/CDR/DWG/PLT/DST | ||
| Applicable materials | Fabric, leather, wood, acrylic, PVC, rubber, bamboo, paper, and other non-metallic materials | ||
Configurations
Laser Cutting Head
The fully enclosed laser cutting head is height-adjustable and features a built-in flame retardant system, ensuring excellent cutting results.
Linear Guide Rail
This system uses ball bearings for power transmission between the guide rail and the slider. It has a simple lubrication structure and provides smooth and efficient operation.
Control System
The control system boasts a clear display and stable signal. It is easy to operate with both buttons and a touch screen, offering a fast response time.
Water Chiller
The branded water chiller efficiently lowers the laser tube's temperature, extending its operational time and lifespan.
