MBB Cell Stringer Machine, AM050F
Request a Quote
Used for automatic multi busbar PV cell soldering
MBB cell stringer machine of AM050F is a crystalline silicon solar cell string production machine combining functions of soldering and lossless cutting. The cell stringer can be applied to 3BB-16BB cells of 161-230mm. The cutting mechanism can cut half and 1/3 cells without material loss, and the soldering mechanism can be repurposed to produce 1/3, half and full cells of 161-230mm. The stringer machine adopts advanced automation technologies in terms of PLC, servo motor, four-axis industrial robot and machine vision to realize automatic production of cell strings.
Technical Parameters
| Item | Parameters | ||
| Normal cell | MBB cell | ||
| Basics | Utilization rate | ≥ 95% | |
| Production capacity | 18Xmm cell: 3BB-12BB >6,800 half cells/h 18Xmm cell: 13BB-16BB >6,400 half cells/h 230mm cell: 3BB-12BB >6,800 half cells or 1/3 cells/h 230mm cell: 13BB-16BB >6,400 half cells or 1/3 cells/h | ||
| Breakage rate | 140-150mm monocrystalline silicon cell: ≤0.4% 151-170mm monocrystalline silicon cell: ≤0.3% 171-230mm monocrystalline silicon cell: ≤0.2% | ||
| Average laser power | 50 W/300W | ||
| Laser warranty | 20,000h | ||
| Testing | CCD | ||
| Deviation | Positioning ±0.05mm Angle±0.04° Cutting±0.1mm | ||
| Laser grooving length | < 1.5mm | ||
| Laser grooving depth | 0-65% adjustable | ||
| Soldering assistance method | Soaking soldering belt | ||
| Soldering method | Infrared soldering | ||
| Temperature change | ±7.5℃ | ||
| Cell | Size | 130～230mm 1/3, half and full cells | |
| Busbar number | 3BB-16BB | ||
| Gap | Busbar gap≥13mm Gap between cell side and busbar>5mm | ||
| Soldering pallet gap | ＞5.5mm | ||
| Thickness | 140～200±10µm | ||
