Absorbent Gauze Folding and Rolling Machine

Request a Quote

Website: http://packingmachine-inc.com/2-47-absorbent-gauze-folding-and-rolling-machine.html

Model: PPD-GFRM90
Product layers: 4-ply (2 folds)
Max. web width: 900mm
Unwind core diameter: 76mm
Max. unwind diameter: 700mm
Finished roll width: 220mm
Speed: 10-150m/min
Power: 2.2kW
Voltage: 380V, 50Hz, 3PH

Applications
The absorbent gauze folding and rolling machine is suitable for automatically folding gauze inward into four layers. It features automatic folding and precise winding, with easy operation, high speed, and stable performance.

Features

• Adjustable gauze winding diameter and folding width, which can be set according to requirements
• The maximum winding diameter is 450mm, the maximum folding width is 220mm, and the winding mandrel diameter is 10mm for 100-yard rolls
