10L-40L Oxygen Concentrator
Different from ordinary pressure oxygen machines, high pressure oxygen concentrators refer to the oxygen concentrating machines whose outlet pressures are in the range of 0.14-0.4Mpa.
As our research and development ability improve, our company has developed more types of oxygen machines to meet market demands. The JAY-10/20/40-4.0 10L-40L oxygen concentrator we produce is suitable for being applied into industrial and medical field.
Considering this is high-power oxygen equipment and may need to keep working continuously for a long period of time, we optimize the machine structure and improve heat dissipation performance to guarantee its stable oxygen concentration. With iron housing, this oxygen concentrator is free from damage.
It is a cost-efficient product you deserve to have. We have the ordinary pressure type oxygen generator with outlet pressure of 0.04-0.07Mpa and the high pressure type ones with outlet pressure of 0.14-0.4Mpa for your selection.
Technical Parameters| Model | | | |
| Flow Rate | 1-10L | 1-20L | 1-40L |
| Outlet Pressure | 60PSI | ||
| Oxygen Concentration | 93%(±3%) | ||
| Power Consumption | ≤1250W | ≤2000W | ≤4440W |
| Net Weight | 90kg | 118kg | 256kg |
| Dimension | 590*460*1300mm | 957.5*500*1327mm | 920*895*1450mm |
| Alarms | Power failure alarm, High/low pressure alarm, Low oxygen concentration alarm | ||
- Features
- High efficiency three-tower adsorption system, more durable
- Pressure gauge on site to adjust flexibly if necessary
- Small and compact, easy to move for any emergency
- Automatic dehydrator/refrigerated air dryer.
- Optional: Auto off at 4 bar, auto on at 3 bar.
- Application
- Applied with ventilator or anesthesia machine at ICU & operating room.
- Applied to hyperbaric oxygen chamber.
