Desktop Dispensing Robot

Request a Quote

View All: http://automated-system.com/3-2-desktop-dispensing-robot.html

This desktop dispensing robot has powerful functions and can complete dispensing and potting operations with high quality. It can process precision products such as integrated circuits, printed circuit boards and electronic components and is widely used in industries of electronic goods, LED lamps, intelligent household appliances, packaging boxes, etc. By realizing many processes that manual dispensing cannot complete, the robot can greatly improve production efficiency, quality and reduce labor costs.

Characteristics

Equipped with four-axis stepper motor, the dispensing robot can precisely control the position and volume of dispensing.
Equipped with a programmable dispensing control system, the robot has functions of position correcting, copying, arrangement and automatic positioning. It can realize any dispensing pattern in plane such as X, Y, W and spiral shaped pattern.
Double-Y-axis working form is available for you to realize alternate processing, which maximizes the production capacity.
Single-screwdriver-head, double-screwdriver-head, horizontal, tilted and rotary dispensing all can be achieved with this robot. You can also choose the special tilted rotary dispensing to realize fast circumference dispensing.

Technical parameters

Dimension：630*620*800mm(L*W*H)
Working range：500*420*110mm(X*Y*Z)
Design capacity：800~1000pcs/h
Dispensing accuracy：±0.5g
Equipment accuracy：±0.15mm
Drive mode: 4 axis precision stepper motor
Control system：PLC motion control system
Program memory: 256 sets, 400 points/set
Dispensing mode: one end, double-end, horizontal, tilting, rotary
Dispensing control system: handheld and programmable
COM port：USB
Power supply：AC220V，50HZ
Total power：350W
Air pressure：0.5-0.7MPa
Net weight：30Kg
Rated current：5A
Air pressure：0.5MPa
Design capacity：50~60pcs/h
Product qualification rate：≥85%
Control system: PLC+human interface
