Introduction

The SR-2000Ex explosion proof infrared gas analyzer can be used to detect the designated gas content in mixed gas backgrounds such as CO, CO2, CH4, SO2, NH3, H2O, NOx and other hydrocarbons. The explosion resistant gas analyzer will avoid explosions, even if the machine breaks down or sparks at high temperatures.

Features
  • Non-dispersive infrared rapid gas analysis technology
  • High accuracy infrared detector with integrated interference filters
  • New electrical modulated infrared light source, filming gas chamber which is easy to disassemble, embedded data acquisition system.
Gases to be detected

Diatomic molecular gas: CO, CO2, CH4, NH3, SO2, NOx and hydrocarbons, etc.

Main specification
Range 0-100%
Repeatability Cv£1% FS
Zero drift £±1% FS/7D
Span drift £±1% FS/7D
Response time T90< 20S
Sample gas flow rate 500mL/min
Preheating time 20min (Optional); 120min(Maximum accuracy)
Signal output 4-20mA/750Ω, RS232/485 (Optional)
Alarm High-limit alarm, low-limit alarm
Temperature and humidity 0-45°C, 20-80%RH
Power supply 220VAC, 50Hz
Explosion proof level Ex dII CT6 (Including Acetylene)
Protection level IP65
Analyzers that we produced before:
  • Explosion proof carbon monoxide analyzer
  • Explosion proof carbon dioxide analyzer
  • Explosion proof ammonia analyzer
  • Explosion proof sulfur dioxide analyzer
  • Explosion proof methane analyzer
Application areas

Chemical fertilizer, chemical industry, petroleum, metallurgy, building materials, power plants, cement, environmental protection, agriculture, medical and other industries.

  • Ammonia Production Gas Analyzing
  • Thermal Power Generation Gas Analyzer
