Automatic Baling Press, Fully Automatic Baler for Waste & Recycling
Request a Quote
The baling press is used to perform baling and recycling on waste paper, cardboards, etc. in a fully-automatic manner. This baling machine mainly consists of bale chamber, main hydraulic cylinder, energy saving hydraulic system, hopper, hydraulic cylinder for compressing bale, MITSUBISHI PLC control system, automatic tying mechanism, etc. Newly designed oil circuit allows for high working efficiency with low consumption. Automatic tying system wraps tie steel wires around the bale after the bale is completely compacted, which prevents it from becoming loose. Featuring high baling speed, it's a type of modern automatic waste recycling equipment.
Specifications| Item | Model | |||
TY-30T | TY-60T | TY-80T | TY-100T | |
| Power | 15kW 380V 50Hz, 3-phase | 18.5kW 380V 50Hz, 3-phase | 22kW 380V 50Hz, 3-phase | 30kW 380V 50Hz, 3-phase |
| Machine weight (T) | 6 | 7 | 8 | 9 |
| Dimensions (L*W*H mm) | 5300*2000*1800 | 6800*3200*2000 | 6800*3200*2000 | 7200*3400*2200 |
| Output (Ton per Hour) | 1~1.5 | 2~3 | 2.5~3.5 | 4~5 |
| Feeding size (mm) | L1000*W550 | L1200*W750 | L1400*W750 | L1600*W800 |
| Baled size (mm adjustable L) | W550*H650 | W750*H750 | W750*H750 | W800*H900 |
| Quantity of straps | 3 | 4 | 4 | 4 |
| Oil tank (L) | 400~500 | 800 | 900 | 1000 |
| Conveyor belt | 800mm width, 3kW | 1000mm width, 4kW | 1200mm width, 5.5kW | 1400mm width, 5.5kW |
| Cooling system | Water cooling tower | |||
| Safety protection | 1 Emergency stop button for baler, 1 for conveyor | |||
| Note: Hydraulic oil should be bought by the user. | ||||
