8108L Double Drum Vibratory Roller
Request a Quote
8108L Double Drum Vibratory Roller
This product has been discontinued and removed from our shelves.
1. Quality engine delivers great power, low emission and fuel consumption.
2. Mechanical drive powers the axle for traveling. Electro-hydraulic control provides two vibration amplitudes. Hydraulic steering hinge is another value-added feature to the vibratory roller.
3. Two braking systems are used, including the hand brake and air-over-oil operated foot brake, for safety and reliability.
4. Compact design, curved hood with esthetic appeal.
5. Airy driver’s cabin with optional air-conditioner for cooling and heating.
6. Optional cam-driven vibrating drum for poweful compaction of cohesive soil.
| Model | 8108L |
| Length×Width×Height(mm) | 5500×2300×3000 |
| Operating weight(Kg) | 10000 |
| Nominal Vibration Amplitude high/low(mm) | 1.74/0.82 |
| Frequency(HZ) | 32 |
| Centrifugal-Force high/low(KN) | 198/93 |
| Gradient capacity (%) | 25 |
| Wheel base(mm) | 2900 |
| Diesel engine | Cummins 4BTA3.9-C100 |
| Rated output(KW) | 80 |
