Application
Silicone sealed E14-3014-LED corn light bulb adopts high transparency silica gel sealing to achieve a 360 degrees illumination without blind angles as well as high luminous power and enhanced brightness. Application sites of the LED light product include malls, hotels, bars, residential housing and other situations requiring illumination.
Specification
E14-3014B-57LED AC/DC 12V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | AC / DC10-16V | Silica gel | 9.6g | 160-180 lm | 70-80 lm/W | 2.0-2.3W | 0.7-1.0 | 360° | 57x3014SMD | No | CRI≥80 |
E14-3014B-58LED AC110/220V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | AC110V / 220V | Silica gel | 9.8g | 160-180 lm | 70-80 lm/W | 2.2-2.4W | ＞0.32 | 360° | 64x3014SMD | No | CRI≥80 |
E14-3014BD-64LED AC110/220V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | | AC110V / 220V | Silica gel | 9.8g | 150-170 lm | 70-80 lm/W | 2.7-2.8W | ＞0.95 | 360° | 64x3014SMD | Yes | CRI≥80 |
E14-3014B-64LED AC110/220V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | AC110V / 220V | Silica gel | 9.8g | 160-180 lm | 70-80 lm/W | 2.3-2.5W | ＞0.32 | 360° | 64x3014SMD | No | CRI≥80 |
E14-3014B-72LED AC110/220V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | AC110V / 220V | Silica gel | 11.4G | 190-210 lm | 75-85 lm/W | 3.0-3.3W | ＞0.93 | 360° | 72x3014SMD | Yes | CRI≥80 |
E14-3014B-104LED AC110/220V E14 SMD Corn LED Light | Finished product | Dimension diagram | Voltage | Material | Net weight | Luminous flux | Luminous efficacy | Actual power | Power factor | Beam angle | LED number | Dimmable | Remark |
| | | AC110V / 220V | Silica gel | 12g | 250-270 lm | 70-80 lm/W | 3.2-3.4W | ＞0.46 | 360° | 64x3014SMD | No | CRI≥80 |
Lamp cap specification
Color temperature
Warm White (2800~3000K)
Natural White (4000~4500K) - Daylight White (6000~6500K)
Feature
1. Silicone sealed E14-3014-LED corn light bulb features fine heat radiation and high insulation.
2. The LED light bulb uses 3014 SMD LED beads as the light source, to achieve low energy consumption, low luminous decay, small heat emission and a long service life of 30 to 50 thousand hours.
3. Silicone sealed E14-3014-LED corn light bulb features gentle light, high luminous efficacy, instant lit after turning on, and bears no strobe or light spots, ensuring that the product protects customers' eyes effectively.
4. The LED light bulb contains no mercury, emits no electromagnetic interference radiation, and is environmental friendly.
5. Silicone sealed E14-3014-LED corn light bulb applies high transparency silica gel to seal its lamp body, and therefore gains the benefit of a 360 degrees illumination without blind angles as well as high luminous power and enhanced brightness.
6. The LED light bulb adopts linear constant current intelligent IC to effectively protect the LED and promote stability.
7. The LED light product has a range of color temperature for customers to choose from.
8. Silicone sealed E14-3014-LED corn light bulb has high luminous power and outstanding CRI, and suffices to replace the traditional halogen lamps and filament lamps.
Packaging style
Shunfa is a reliable E14 LED bulb and SMD LED manufacturer, E14 3014 SMD LED bulb supplier, offers all kinds of bin-pin LED bulbs and SMD LED bulbs for home lighting, commercial lighting, industrial lighting, etc. Fully equipped with surface mount and silicone encapsulation equipment, we provide quality E14 LED light bulbs with custom service.
