Scaffold QES Steel Plank
Scaffold QES Steel Plank
Scaffold QES Steel Plank

Scaffold QES Steel Plank

Description

The hook on the steel plank can hang onto the horizontal braces of QES scaffold system and thus form a working face for building construction.

Surface treatment

Hot galvanizing

Material

Q235 steel

Specification

Width: 10", Height: 63mm, Thickness: 1.8mm.

Item No. Description Weight (kgs)
Q19-4 4' Steel Plank QES 21.8
Q19-5 5' Steel Plank QES 25.9
Q19-6 6' Steel Plank QES 29.2
Q19-7 7' Steel Plank QES 34.1
Q19-8 8' Steel Plank QES 38.1
Q19-9 9' Steel Plank QES 41.58
Q19-10 10' Steel Plank QES 46.2
