BC05 Three-pin Circular Connectors (for Micro Inverter)
Request a Quote
This product has been discontinued and removed from our shelves.
This photovoltaic AC connector is used for the connection of micro inverters and the bus cable. The use of high-quality engineering plastic PPO/PC and the excellent sealing performance ensure the reliability and performance. This PV connector also features an excellent resistance to UV light, salt spray, high temperatures, vibration and shock.
BC05
- Electrode cores: three-core
- Main line rated voltage and current: 300V 30A
- Branch line rated voltage and current: 300V 8A
- Waterproof Rating: IP68(1.5m,24h)
- Flammability Rating: UL94-V0
- Insulation resistance: >5MΩ
- Insulation voltage: 1500V AC (10mA,1Min)
Technical Parameters
General
| Pin Number | 2P PE |
| Main Line Rated Current | 32A (Use 10AWG/6mm² copper cable) |
| Main Line Rated Voltage | 300V |
| Branch Line Rated Current | 12A (Use 16AWG/1.5mm² copper cable) |
| Branch Line Rated Voltage | 300V |
| Contact Resistance | ≤5mΩ |
| Power Frequency Withstand Voltage | 1500V AC |
| Over-voltage Category | Ⅲ |
| Closure Pollution Degree | 2(mated) |
| Protection Class | IP68(1.5m, 24hour) |
| Withdraw Force | 50~100N |
| Flammability Rating | UL94-V0 |
| Rated Temperature | -40℃~ 85℃ |
Connection Data
| Applicable Cable Specification | Main Line: 14/12/10AWG; branch: 16/18AWG |
| Applicable Cable Outer Diameter | Main Line: 10~13mm; branch: 7~9.5mm |
| Locking System | Snap |
| Main Line Connection | Screw Pressing |
| Branch Line Connection | Crimping |
Materia
| Housing Material | PPE |
| Terminal Material | Copper zinc alloy |
| Terminal Surface Treatment | Main line: tin-plated; branch line: gold plated |
| Sealing Material | Silicon rubber |
Standards
| PPP 59015A:2013 | TUV test standard |
| ANSI/UL6703-2017 | CSA test standard |
| RoHS Compliant | Yes |
Dimensions
| Length | 150mm |
| Width | 40mm |
| Height | 110mm |
