200KVA MFDC Longitudinal Seam Welder
Request a Quote
The 200 kVA MFDC longitudinal seam welder is designed for cylindrical workpieces and longitudinal seam welding applications. Its rigid structure, stable clamping system, and MFDC inverter technology support consistent seam quality in continuous production.
ApplicationsThis longitudinal seam welder is suitable for seam welding applications of a wide range of materials, including:
- Non-ferrous metals
- High-temperature alloys
- Low-carbon steel
- Stainless steel
- High-strength steel
- Galvanized steel
- Aluminum alloys
| Model | FB-200-L** | |
| Rated Capacity | kVA | 200 |
| Power Supply | V/Ph/Hz | 380/3/50 |
| Max. Primary Current | A | 136 |
| Primary Cable | mm2 | 50 |
| Max. Short-Circuit Current | kA | 35.3 |
| Rated Duty Cycle | % | 10 |
| Secondary No-Load Voltage | V | 10 |
| Welding Cylinder Size | Ø×Stroke | Ø160×80 |
| Max. Electrode Force | N | 10000 |
| Compressed Air Pressure | MPa | 0.6～0.7 |
| Cooling Water Flow Rate | L/min | 33 |
| Compressed Air Consumption | L/cycle | 5.84 |
| Throat Depth | mm | 1147 |
| Arm Gap | mm | 115 |
| Electrode Size | mm | Ø250×20 |
| Dimensions (H×L×W) | mm | 2368×2274×1263 |
Heron is engaged in making resistance welding system, is an experienced metal electric resistance seam welding machine manufacturer and welding solution provider. Since 1997 we have been offering wide range of MFDC resistance spot welders, MFDC resistance seam welders, DC resistance projection welding machines and robotic welding system for global customers.
