High Performance and Energy Efficient 4 Wheel Electric Forklift Trucks
Request a Quote
Our four-wheel electric forklift operates with excellent stability and power to handle goods in the aisles of warehouses with different widths. It features a load capacity of 2.5T and the lifting height can reach 6m, significantly greater than the compact 3-wheel units. The machine can be equipped with optional features like solid tires, side-pull cells, side shifters, full free lift tool, and other attachments to enhance performance according to your needs.
Features
-
Safety
- Each 4-wheel electric forklift is equipped with an emergency button whose role is to cut power to the machine immediately.
-
Easy operation
- Italian ZAPI display clearly shows your battery power level, fault codes, and operating times. This optimizes operation and maintenance efforts.
- A forklift deceleration device is designed to automatically kick in when the fork is descending down to 10 cm from the ground. It ensures a smooth landing.
-
High efficiency
- AC power greatly increases speed and acceleration, enhancing working efficiency.
- The drive motor with a transverse design provides greater accumulator capacity and a low forklift center of gravity.
- High braking performance
- The electric forklift performs automatic braking when the accelerator is released. This prevents the forklift from moving down ramps and other sloped surfaces.
- Low maintenance cost
- The application of an AC motor means you do not need to replace parts regularly like carbon brushes and commutators. The electrical motor is also emissions free, meaning it can be used indoors, even in compact spaces.
Technical parameters
Model | | CPD20A | CPD25 |
Drive | | Electric | |
Rated capacity/rated load | Q(kg) | 2000 | 2500 |
Load center distance | C(mm) | 500 | |
Lift height | h3(mm) | 3000 | |
Free lift | h2(mm) | 140 | |
Mast/fork carriage tilt forward/backward | α/β(°) | 6°/12° | |
Lowered mast height | h1(mm) | 2045 | |
Overhead guard height | h5(mm) | 2205 | |
Ground clearance at center of wheelbase | m1(mm) | 110 | |
Length to face of forks | l2(mm) | 2418 | |
Overall width | b1(mm) | 1150 | |
Fork dimensions | s/e/l(mm) | 40×125×1070 | |
Fork width | mm | 250/1040 | |
Load distance, center of drive axle to fork | x(mm) | 478 | |
Turning radius | Wa(mm) | 2130 | |
Extended mast height | h4mm | 4145 | |
Aisle width for pallets 1000×1200 crosswise | Ast(mm) | 4110 | |
Aisle width for pallets 800×1200 lengthwise | Ast(mm) | 4025 | |
Travel speed, laden | km/h | 12.5 | |
Travel speed, unladen | km/h | 13.5 | |
Lift speed, laden/unladen | mm/s | 260 | |
Lowering speed, laden/unladen | mm/s | 400 | |
Max gradeability, laden | % | 15 | |
Max gradeability, unladen | % | 15 | |
Service brake | | Hydraulic | |
Steer wheel size | | 7.00-12-12PR | |
Load wheel size | | 18×7-8-14PR | |
Track width, front | mm | 970 | |
Track width, rear | mm | 950 | |
Wheelbase | mm | 1500 | |
Service weight including battery | kg | 3920 | 4120 |
Axle loading, laden front | kg | 5062 | 5777 |
Axle loading, laden rear | kg | 858 | 843 |
Axle loading, unladen front | kg | 1568 | 1648 |
Axle loading, unladen rear | kg | 2352 | 2472 |
Drive motor | kw | 11 | |
Lift motor | kw | 9.5 | |
Battery voltage, nominal capacity K5 | V/Ah | 48/560 | |
Type of drive control | | AC | |
Manufacturer of drive control | | ZAPI | |
Operating pressure for attachments | Mpa | 17.5 |
Headquartered in Ninghai, China’s hub of forklift trucks manufacturing, Cholift Forklift Co. is a trustworthy producer of reliable material handling equipment. Our warehouse equipment include electric forklifts, electric pallet jacks, pallet trucks, hand pallet jacks, and lift table carts. In addition to these outstanding products, we can also offer customers complete handling and industrial storage solutions according to their requirements.
Photos Gallery
- Warning lights
- Overhead guard (good view)
- Steering wheel (easy operation)
- Suspension seat
- Instrument panel
