Automatic Gummy Candy Weighing Packaging Line
This automatic gummy weighing packaging line is designed for solid or piece-type confectionery such as gummy candies. It integrates automatic feeding, precise weighing, and high-speed packaging into a compact system measuring approximately 4.5 m × 3.5 m, fully compliant with CE food-grade standards.
The candy packaging line consists of a bucket elevator, working platform, multihead weigher, vertical form fill seal (VFFS) packaging machine, and finished product conveyor. The production line enables fully automated weighing, bag forming, filling, sealing, and conveying, offering high accuracy, high efficiency, and intelligent control. It is ideal for medium- to large-scale continuous production.
| Model | ||
| Bag Length | 150-400 mm | 100-350 mm |
| Bag Width (Front) | 80-250 mm | 50-200 mm |
| Bag Width (Side) | 40-150 mm | 35-100 mm |
| Sealing Width | 5-10 mm | 5-10 mm |
| Max. Film Width | 620 mm | 520 mm |
| Packaging Speed | 15-45 pcs/min | 15-50 pcs/min |
| Air Consumption | 0.68 m3/min | 0.60 m3/min |
| Air Pressure | 0.65 MPa | 0.65 MPa |
| Power | 8 kW | 7.5 kW |
| Machine Weight | 880 kg | 750 kg |
| Film Material | Laminated film (OPP/CPP, OPP/PE, PET/PE, aluminum film) | |
-
Bucket Elevator
The food-grade conveying structure ensures smooth and continuous feeding of gummy products into the weighing system, reducing product compression, sticking, and deformation, maintaining product integrity and appearance quality.
-
Working Platform
Made of food-grade stainless steel, the platform supports the installation and operation of the multihead weigher and facilitates manual feeding and operation.
-
Multihead Weigher
Equipped with high-precision load cells and intelligent combination algorithms, the multihead weigher enables fast and accurate quantitative weighing, improving weighing accuracy and production efficiency while meeting various packaging requirements.
-
VFFS Packaging Machine
Automatically completes bag forming, metered filling, sealing, and cutting. Compatible with various bag types such as pillow bags and back-seal bags, ensuring firm and consistent sealing quality and meeting diverse packaging requirements.
