Lead-acid Battery Heat Sealing Machine
Request a Quote
Lead-acid Battery Heat Sealing Machine
This lead-acid battery machinery is used for heat sealing the top cover to the battery container. It features PLC control and HMI operation, realizing automatic feeding, positioning, sealing and discharging.
Main Features
- Fully enclosed working condition
- High level of automation
- Comes with pre-heating function, and timer-controlled heating
- Working parameters can be stored, recalled and re-edited.
- Features force-air cooling system
Technical Specifications
- Heat sealing die temperatureMax. 350℃
- Temperature control error≤±2℃
- Temperature measuring error≤±0.5℃
- Heating duration from 25℃ to 350℃Less than 30 minutes
- Melting time0.1～99.9 seconds, adjustable
- Sealing time0~99 seconds, adjustable
- Melting depth2.5mm
- Battery height ultimate error after sealing≤0.5mm
- Sealing efficiency300 batteries/h (at 100AH/12V)
- Total electric power8kW
- Air supply0.4~0.8MPa, 6.8L/min
- Machine dimension1550 x 1200 x 2100mm
- Machine weight500kg
