BP-8164-B Melt Flow Index Tester
Request a Quote
Laboratory testing equipment for rapid testing of melt mass flow rate (MFR) and melt volume rate (MVR) of plastics and polymer products
- PLC control
- Standard: ASTM-D1238, ISO-1133, GB/T3682
- Measuring methods: MFR/MVR
- Measuring scope: 1.0-100g/10min, 0.01-350cm³/10min
The melt flow index tester is designed to measure the melt mass flow rate (MFR) and melt volume flow rate (MVR) of thermoplastic resins. The melt flow index texter is suitable for testing high-melting point materials such as polycarbonate, nylon, fluoroplastics, and polyphenylsulfone, as well as low-melting point plastics like polyethylene, polystyrene, polypropylene, ABS resin, and polyoxymethylene (POM). Widely used across industries such as plastic materials, products, and petrochemical, as well as in research institutions, universities, and inspection departments.
Technical Data
- Measuring method
mass melt flow rate (MFR)/melt volume rate (MVR) - Measuring scope
1.0-100g/10min, 0.01-350cm³/10min - Temperature control range
50-450℃ - Temperature control accuracy
±0.1℃ - Temperature display resolution
0.1℃ - Temperature recovery time
<4min - Cutting method
automatic cutting - Material cutting time interval
1-180000s - Timing accuracy
0.01s - Displacement measurement accuracy
±0.1mm - Heating time
<30min - Power supply
AC220V, 50Hz, single-phase 3-wire - Dimensions (W×D×H)
550×435×880mm - Weight
62kg
