CO 2 Laser Cutter for Metal & non-metal Products BCL-BM Manufacturer

CO 2 Laser Cutter for Metal & non-metal Products BCL-BM

Request a Quote

View All: http://lasercutter-engraver.com/2-2-metal-non-metal-co2-laser-cutter-engraver-rj-1325p.html

CO₂ Laser Cutting Machine, CO₂ Laser Cutting System

This product has been discontinued and removed from our shelves.

2 Laser Cutter for Metal & non-metal Products BCL-BM" />

Introduction

The BCL-BM CO₂ laser cutter for metal & non-metal products is equipped with a 150W CO₂ laser for cutting carbon steel sheets with a maximum thickness of 1.5mm, and stainless steel sheets with a maximum thickness of 1.2mm. It is available at a fair price, and features a wide processing range with a large working area, thus giving it a high cost performance.

The optical path system is extremely precise. Consisting of 5 mirrors and 1 concentrator, the optical path system produces a high-power CO₂ laser beam, making the cutting process more efficient and the cutting surface smoother.

Standard configuration

Red cross-line laser alignment system
Internal LED light
Aluminum slat cutting table
Ruida DSP control system
Hotspur CO₂ laser tube
Exhaust fan
S&A water chiller

Optional configuration

Electric lifting worktable
Auto focus
Rotary axis
Aluminum honeycomb cutting table
Fume extractor

Materials

Wood
Paper
Cloth
Leather
Plexiglass
Epoxy resin
Acrylic
Plastic
Crystal
Jade
Tile
Light metal

Parameters

Model	BCL1325BM	BCL1530BM
Working area	1220*2500mm	1500*3000mm
Transmission	Belt	Ball screw
Laser power	150w
Laser type	Sealed CO₂ laser tube,10.6μm
Cooling type	Water cooling
Laser output control	(0-100% Set by software )
Highest scanning precision	4000DPI
Positioning accuracy	0.05mm
Positioning speed	20m/min
Max. cutting thickness	30mm
Max. cutting speed	20m/min
Power supply	AC110V/220V 10%,50HZ/60HZ
