B Series LED Downlight, LED COB Light with Round Cover
Request a Quote
Features
- B Series LED Downlight features a split design. We can use embedded installation or integral installation. The installation method is convenient, and will not damage the ceiling or light.
- Lenses and reflectors are available in two optical forms. They are suitable for different areas of hotel lighting and wall lamps.
- It is a modular design, so different round covers, ellipse covers, and reflectors can be replaced easily to meet the needs of customers.
- New patented mounting clip design with multiple installation methods that will not damage its elasticity.
- The die-casting aluminum materials with high efficiency heat dissipation structure delivers superior heat dispersion.
- High quality LED light sources to choose from: Citizen COB, and Cree COB.
- The surface of the radiator is painted with a titanium color, and the surface of the front cover is white painted, giving an exquisite workmanship appearance.
Specification
- LED Chip Citizen/CREE COB
- LED Driver Tridonic, Philips, OSRAM, Lifud, BOKE and others are available
- Dimming option Non-dimming, DALI, TRIAC, 0/1-10V, DMX, RF, ZigBee
- PF >0.9
- Input Voltage AC220-240V/AC100-240V 50/60Hz
- CRI 80+90+97+
- CCT 2700K, 3000K, 4000K, 6000K
- Luminous Efficacy 60-80 lm/W @CRI80 (whole lamp)
- Lens beam angle 15°,24°,35°
- Reflector beam Angle 15°,24°,38°
- Body Material ADC12 die-casting aluminum alloy
- Light color Warm white, pure white, cool white
- Adjustable 360° rotation horizontally and 25° pivot
- Housing color White ring and Titanium color heat sink
- Lifespan 50000 hours
- Warranty 3-5 Years
Dimension
7W-12W
Product Models
| Model No. | Power | Fixture Dimension | Cut Hole Dimension | |
| BH-DL-07W-B | 7W | Φ86*H106mm | Φ75mm | |
| BH-DL-12W-B | 12W |
