Slitter Rewinder for NCR Paper/ Carbonless Copy Paper (2ply/3ply)

Request a Quote

View All: http://packingmachine-inc.com/2-26-slitter-rewinder.html

Model: PPD-2PLY900/PPD-3PLY900
Web width: 900mm
Master roll diameter: 1000mm
Finished roll diameter: 150mm
Rewinding paper core diameter: 12.7mm or customized
Unwinding paper core diameter: 3 inch
Max. machine speed: 150m/min
Power supply: 3 Phase 380V 50Hz

Applications
This slitter rewinder is typically designed for converting various types of 2-ply or 3-ply carbonless copy paper, thermal paper, POS paper, cash register paper, etc. It is also suitable for slitting 1-ply fax paper, billing paper, medical recording paper, ATM receipt paper, etc. There are two models of web width 800mm and 900mm are available to meet your specific needs.

Features

Siemens PLC control with HMI operation;
Variable frequency speed control;
Automatic tension control;
Two-shaft/three-shaft center-surface winding method;
Pneumatic loading unit;
Line making unit and single ply slitting & rewinding unit are configurable;
The machine is featured by superior look, compact structure, high automation and easy to operate;
