28mm Metal Shaft 10K ohm Rotary Potentiometer Switch, WH028-1
Request a Quote
Part Number
WH028-1
WH028-1 rotary potentiometer switch are made using a polymer plastic material and adaptation to high power applications. They are especially suitable for power tool speed adjustment.
Parameters
| Diameters | 28mm |
| Shaft | metal |
| Total rotational angle | 260°±10° |
| Rotational torque | 20~200gf.cm |
| Stopper strength | ≥6kgf |
| Total resistance | 10K-1MΩ |
| Resistance tolerance | ±20% |
| Element | carbon film |
| Rated power | ≤0.5W |
| Voltage Resistance | 500V AC for 1 minute |
| Operating life | ≥10000cycles |
Dimensions
