Aggregate Spreader

Request a Quote

View All: http://sgroadmachine.com/2019/6-2-aggregate-spreader.html

Aggregate spreaders are specialized equipment for spreading aggregate, and we are able to customize these spreaders to meet specific customer needs.

Parameters of Aggregate Spreader GYSS1631J:

Model	GYSS1631J
Spread Width	3100mm
The Number of Discharge Gates	16
The Particle Size of Aggregate	3～30mm
Spread Amount	0.5m3～50m3/km2
Dimension	1900mm(L)×2500mm(W)×2100mm(H)

Features:

The operator can individually control the 16 discharge gates. As a result, the spread width is easily adjustable.
The discharge gate is equipped with a micro-adjusting mechanism to adjust a single discharge gate, thus ensuring a uniform aggregate spread.
The operator can lift the hopper using the operator cab or operator console.
The aggregate spreader is equipped with a lighting system for operation at night.
The alarm limit switch will automatically alarm to warn the operator when the hopper is lifted to a certain height, ensuring construction safety.
The aggregate spreader is used to spread the aggregate within an area of 3-30mm by adjusting the inclination angle of the material separation plate and blanking panel.
The gas path system is equipped with a filtration system to remove the moisture and impurities, leading to a highly reliable gas path system.
