Automatic Clothes Hanger Making Machine
Request a Quote
Features
- This automatic clothes hanger making machine adopts servo motor to feed wire, with high speed and high precision. Comparing with traditional wire hanger making machine, 100% rate of finished products can be achieved by the automatic machine.
- Adopt PLC control, HMI operation, simple and convenient to operate.
- Forming tool can be easily changed to produce hanger with different sizes.
- Can be optionally equipped with a counter.
Technical Parameters
| Item | ||
| Applicable wire | Plastic coated wire | Carbon steel wire, stainless steel wire |
| Applicable hanger size | 11-14’’(Children), 15-19’’(Adult) | 11-14’’(Children), 15-19’’(Adult) |
| Wire thickness(mm) | 1.6-4.5 | 1.5-3.5 |
| Production speed(pieces/min) | 25-40 | 25-40 |
| Machine dimension(mm) | 1400x1000x1600 | 1400x1000x1600 |
| Machine weight(kg) | 900 | 950 |
| Power supply | 380V, 3phase, 50Hz or as required | 380V, 3phase, 50Hz or as required |
