Welding Rotary Table & Welding Turntable
Request a Quote
Welding rotary tables provide a stable horizontal surface that can rotate workpieces during welding or assembly. By turning the workpieces smoothly, the rotary tables allow welders to reach all areas without manually repositioning the workpiece. These rotary tables are widely used to position various types of workpieces in steel fabrication workshops, and the rotation can be controlled to match the welding process for consistent results.
Specifications
| Model | |||||||
| Rated load (kg) | 5000 | 10000 | 20000 | 50000 | 100000 | 150000 | 250000 |
| Rotation speed (rpm) | 0.05-1 | 0.05-1 | 0.025-0.5 | 0.025-0.5 | 0.015-0.3 | 0.015-0.3 | 0.01-0.2 |
| Speed control method | VFD stepless speed control | ||||||
| Motor power (kW) | 1.1 | 1.1 | 1.5 | 2.2 | 4 | 5 | 7.5 |
| Worktable height (mm) | 650 | 650 | 740 | 750 | 1150 | 1300 | 1400 |
| Worktable diameter (mm) | ⌀1500 | ⌀1800 | ⌀2000 | ⌀2200 | ⌀2500 | ⌀2800 | ⌀2800 |
