Application
1060 aluminum alloy is widely used in the manufacture of railroad tank cars, chemical equipment, ship equipment, conductive material, welding rod, gauge and instrument.
Aluminum alloy state, size and mechanical properties| Alloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
| Chinese standard | Value | ||||
| 1060 | O | ＞0.2-0.3 | 60-100 | 55-95 | ≥15 |
| ＞0.3-0.5 | ≥20 | ||||
| ＞0.5-0.8 | ≥25 | ||||
| ＞0.8-1.3 | ≥30 | ||||
| ＞1.3-4.5 | ≥35 | ||||
| H22 | ＞0.2-0.5 | 80-120 | 100-125 | ≥12 | |
| ＞0.5-1.0 | ≥15 | ||||
| ＞1.0-4.5 | ≥18 | ||||
| H24 | ＞0.2-0.5 | 95-135 | 120-150 | ≥6 | |
| ＞0.5-1.0 | ≥8 | ||||
| ＞1.0-4.5 | ≥10 | ||||
| H26 | ＞0.2-0.5 | 110-155 | 140-170 | ≥2 | |
| ＞0.5-1.0 | ≥4 | ||||
| ＞1.0-4.5 | ≥6 | ||||
| H18 | ＞0.2-0.5 | ≥125 | ≥170 | ≥2 | |
| ＞0.5-1.0 | ≥3 | ||||
| ＞1.0-4.5 | ≥4 | ||||
