Intelligent Ozone Generator Manufacturer

Intelligent Ozone Generator

Request a Quote

View All: http://ntozonegenerator.com/1-1-intelligent-ozone-generator/239343/index.html

OSUNSHINE PLC intelligent controlling ozone generator features an exclusive intelligent power system. Accurate quantitative ozone output makes all kinds of processes economic and practical, whether that is food processing, waste water treatment, clean, or chemical processing. The ozone generator is available with an automatic alarm system and over 20 protection functions, which ensures all-around protection during operation. Additionally, it supports effectively prevention of misoperation so as to avoid potential damages.

Simple operation and get the ozone needed at any time.

Delicate manual work and seek perfection in every detail.

CH-WZQ-PLC —Vertical ozone generator (outside source)
Parameter

Item	Oxygen flow rate	Ozone output	Power	Cooling method	Cooling water flow rate	Voltage	Size	Net weight
Model	L/min	g/h	w	/	L/min	V Hz	mm	kg
CH-WZQ10G	3	10	200	Water cooling	6-10	220 50/60	450×360×840	28
CH-WZQ20G	5	20	310					30
CH-WZQ30G	10	30	400					33
CH-WZQ40G	10	40	460					35
CH-WZQ50G	15	50	530					35
CH-WZQ60G	20	60	700				450×360×960	39

CH-WZQ-PLC—Water Cooling Complete Ozone Generator
Parameter

Item	Oxygen flow rate	Ozone output	Power	Cooling method	Cooling method	Cooling water inlet	Cooling water outlet	Refrigerated air Dryers outlet	Voltage	Size	Net weight
Model	L/min	g/h	w	/	L/min	mm	mm	mm	V Hz	mm	kg
CH-Y10G	3	10	880	Water cooling	6-10	￠ 20	￠ 8	￠ 10	220 50/60	550×800×1100	91
CH-Y20G	5	20	1300								94
CH-Y30G	10	30	1500								98
CH-Y40G	10	40	1600								102
CH-Y50G	15	50	2600							650×1030×1240	172
CH-Y60G	20	60	2800							650×1030×1240	180
CH-Y100G	30	100	5280							670×1090×1250	200
CH-Y200G	60	200	10000		15-20	￠ 32	￠ 20	￠ 20		900×1750×1520	530
