Smart Restroom Management System
With the help of internet, a real-time monitoring can be conducted on people counting, air quality, temperature and humidity of the toilet.
- Quick and easy installation brings about less material waste and almost 100% reusability;
- Smart cloud control system could monitor the real-time state of the restrooms to cut down cost of operation and maintainance;
- A clean and hygienic environment provides users with a pleasant, comfortable, and customary restroom experience;
A 50-inch TV set screen is needed for the system
- Plans of the restroom
- Monitoring
- Real-time temperature and humidity of the toilet
- The air quality index of the toilet
- Toilet water consumption, electricity consumption and the flow of people using the toilet
- Advertisement (Display part for water sewerage)
Smart Restroom Management System
| Number | Content | Configuration | Functions |
| 1 | hall | screen | The screen is divided into several parts to show plans of toilet stalls, monitoring, temperature, air quality index, water sewerage, electricity consumption, people counting and advertisement (either pictures or videos work well). |
| 2 | comfort evaluation | screen for comfort evaluation | The screen is installed below the display, and toilet users can evaluate their feelings about public toilets. |
| 3 | indoors and outdoors monitoring | monitoring | Two security cameras, one for indoors and the other for outdoors. |
| 4 | men's restroom and women's restroom | air quality sensor | Those air quality sensors are installed in men's room and women's room to record the temperature, humidity and air quality |
| 5 | squatting pan and water closet | vacancy indication light alert system smart light system | The vacancy indication light is installed in the upper part of partitions;users could press the alert system button in case emergency happens; the smart light system will be switched on if someone is using the toilet stall |
| 6 | utility room | system host, router, gateway, water meter, electricity meter | The host in utility room is used to control the screen display, monitoring and alert system, and the router and gateway in utility room help keep the free flow of data between host and cloud platform. Water meter and electricity meter will conduct daily record of the toilet. |
| 7 | smart city manygement platform on the mobile phone | App/PC/API | Download an APP in your mobile phone or PC. In this way, you will have a better understanding of real-time operation of public toilets or just upload them via API. |
-
-
The green light of our dashboard shows stalls are empty, while red lights means stalls are being used. This would save users' time of waiting and checking;
-
-
The screen shows which stalls are empty, how many stalls are available, and the approximate queue time;
-
-
Users can make reviews on the sanity, facility quality of our prefab public restrooms so that we could improve our service;
Energy-saving and durable; Visualized display;
Via the internet, a real-time monitoring on the restrooms can be achieved in a highly effective manner.
