Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X

Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Automatic Paper Tube Labeling and Cutting Machine (with White Glue), WT-580X
Request a Quote

This paper can labeling machine adopts water based glue used for gluing label on paper tube. It can be applied to single label or multiple labels at the same time and automatically cut into the required height.

Features
  • The operation is simple and easy to adjust, and the mold processing difficulty is low, which is very suitable for the labeling process of small and medium-sized paper can products.
  • The use of white latex labeling is not easy to be affected by the processing environment and temperature and can improve the molding effect of the subsequent processing process.
  • PLC control system and touch screen are adopted, which is simple and convenient.
Specification
Model WT-580X
Diameter range 50-100mm
Length range 50-580mm
Label thickness 105-157g
Accuracy ±0.3-1.0mm
Tube in Automatic
Tube out Automatic
Rated power 3kw
Host speed 0-1400
Machine weight 500kg
Dimensions 200*104*150cm
Power voltage 220v 50Hz
Air pressure 0.3-0.5kpa
Labeling speed 30-60pcs/min
Control method PLC 7inch touch screen
Operator 1
Blade quantity 5 pcs
Glue type White latex
