90mm 60W Speed Control Motor Manufacturer

90mm 60W Speed Control Motor

Request a Quote

View All: http://zd-drivers.com/1-2-5-speed-control-ac-gear-motor.html

Motor Specifications

Model	Output Power W	Voltage V	Frequency Hz	Speed Control Range r/min	Allowance Torque		Starting Torque mN.m	Current A	Capacitor μF
					1200r/min m N.m	90r/min mN.m
5IK60RGU-AF	60	1ph 100	50	90～1400	460	140	265	1.00	20
			60	90～1700	490	160		1.10
5IK60RGN-EF	60	1ph 110	60	90～1700	490	160	265	0.80	12
		1ph 120						0.85
5IK60RGN-CF	60	1ph 220	50	90～1400	490	140	265	0.50	4.0
		1ph 230						0.55
5IK60RGN-HF	60	1ph 220	60	90～1700	490	160	265	0.50	4.0
		1ph 230						0.55

Gear Motor-Torque TableAllowance Torque Unit: N.m

Type Motor/Gearhead		Gear Ratio		7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	200	166	120	100	83	60	50	41	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	240	200	144	120	100	72	60	50	36	30	24	20	18	15	12	10
5IK60RGU-AF 5IK60RGU-EF 5IK60RGU-CF 5IK60RGU-HF	5GU()RC 5GU()RT	Allowance Torque	50Hz	2.37	2.84	3.95	4.73	5.68	7.89	9.47	10.2	14.2	17.0	20.0	20.0	20.0	20.0	20.0	20.0
5IK60RGU-AF 5IK60RGU-EF 5IK60RGU-CF 5IK60RGU-HF	5GU()RC 5GU()RT	Allowance Torque	60Hz	1.91	2.29	3.18	3.82	4.58	6.36	7.64	8.25	11.5	13.7	17.2	20.0	20.0	20.0	20.0	20.0
