90mm 40W Speed Control Motor Manufacturer

90mm 40W Speed Control Motor

Request a Quote

View All: http://zd-drivers.com/1-2-4-speed-control-ac-gear-motor.html

Motor Specifications

Model	Output Power W	Voltage V	Frequency Hz	Speed Control Range r/min	Allowance Torque		Starting Torque mN.m	Current A	Capacitor μF
					1200r/min m N.m	90r/min mN.m
5IK40RGU-A	40	1ph 100	50	90～1400	260	70	180	0.65	12
			60	90～1700				0.70
5IK40RGN-E	40	1ph 110	60	90～1700	260	65	180	0.55	8.0
		1ph 120						0.60
5IK40RGN-C	40	1ph 220	50	90～1400	300	75	160	0.35	2.5
		1ph 230						0.40
5IK40RGN-H	40	1ph 220	60	90～1700	230	70	145	0.35	2.5
		1ph 230						0.40

Gear Motor-Torque TableAllowance Torque Unit: N.m

Type Motor/Gearhead		Gear Ratio		7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	200	166	120	100	83	60	50	41	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	240	200	144	120	100	72	60	50	36	30	24	20	18	15	12	10
5IK40RGU-A 5IK40RGU-E 5IK40RGU-C 5IK40RGU-H	5GU()RC 5GU()RT	Allowance Torque	50Hz	1.58	1.89	2.63	3.16	3.79	5.26	6.31	6.80	9.50	11.4	14.2	17.0	18.9	20.0	20.0	20.0
5IK40RGU-A 5IK40RGU-E 5IK40RGU-C 5IK40RGU-H	5GU()RC 5GU()RT	Allowance Torque	60Hz	1.27	1.53	2.12	2.55	3.05	4.24	5.09	5.50	7.64	9.16	11.5	13.7	15.3	18.3	20.0	20.0
