Grinding dovetail screw is used as the guide rail of the manual linear stage. Driven by dovetail screw, the stage has higher driven power. The mounting holes are distributed on the base and table in standard distance, which makes it easier to be combined with other series of stages to form multi-axis positioning stage.
We provide 4 models of dovetail manual linear stages, their maximal travel ranges are 50mm, 75mm, 125mm respectively.

Features
  • Dovetail screw set as guide rail allows for higher capacity.
  • grinding lead screw drives the displacement.
  • Grinding lead screw is placed in the center of the stage, allowing higher driving power.
  • The mounting holes are distributed on the base and table in standard distance, which makes the stage easier to be installed and combined.
  • The linear stage can be combined with other series of stages to form multi-axis positioning stage.
WN115TM50L
WN114TM
WN115TM75L
WN116TM
Model WN115TM50L WN114TM WN115TM75L WN116TM
Table size 70mm×35mm 100mm×60mm 110mm×65mm 63mm×60mm
Drive Helical gear rack Grinding lead screw Helical gear rack Screw thread pair
Drive position Central drive Central drive Central drive Central drive
Travel 50mm 13mm 75mm 125mm
Smallest graduation 0.02 10μ 0.02 -
Minimal adjustment 10μ 10μ
Guide type Grinding dovetail screw set Grinding dovetail screw set Grinding dovetail screw set Grinding dovetail screw set
Load capacity 20kg 12kg 20kg 12kg
Straightness 30μ 30μ 30μ 30μ
Table parallelism 50μ 50μ 50μ 50μ
Running parallelism 40μ 40μ 40μ 40μ
Weight 0.75kg 0.7kg 0.85kg 0.65kg
Material Duralumin Duralumin Duralumin Duralumin
Surface Blackened by anodic oxidation Blackened by anodic oxidation Blackened by anodic oxidation Blackened by anodic oxidation
