YCBS35ZB Pad and Film Shrink Wrapper Packing Machine Manufacturer

YCBS35ZB Pad and Film Shrink Wrapper Packing Machine

Request a Quote

View All: http://beverage-packline.com/1-3-2-pad-film-shrink-bundling-machine.html

Application
The YCBS35ZB cardboard film packing machine boasts a packaging speed of 30-35pcs/min and is suitable for shrink film packaging of beer, beverages, fruit juices, bottled water, dairy products, condiments, and so on with bottom support.

Technical parameters

Equipment model	YCBS35ZB
Machine dimension	L16390mmW1800mmH2500mm
Packing speed	30-35 pcs/min
Working voltage/power	3Phase 5Line 380V about 50KW
Working pressure	0.6-0.8Mpa
Air consumption	150NL/min
Total weight	5000KG

Features

Automatic assembly into packages during product transport, which can save time and improve efficiency.
It has the characteristics of user-friendly interface, fast parameter setting, convenient communication and manipulation with touch LCD screen.
Air circulation technology delivers heat insulation and heat preservation, high precision of temperature control, and better packaging effect.
Suitable for packaging of different bottle diameters and different combinations.
This machine can be equipped with pad film shrink packaging and color shrink wrapping system.

When it comes to secondary packaging equipment, Beijing YCTD Packaging Machinery Co. is king! First established in Beijing in 2001, YCTD specializes in the design and production of equipment used to wrap beverages after their initial packaging. With nearly 2 decades of experience, we have become a leading packaging solutions provider, working with some of the largest beverage producers in the world. Some of our partners include, Huiyuan Group, Coca-Cola, Pepsi, Dali Group, Wanglaoji, Cestbon, Ganten, Uni-President Group, and Master Kong. Our main series of products is made up of heat shrinkable packaging machines, case erector packers, stacking systems, and conveying systems. Quality is what drives us forward and we have built a company strategy around delivering quality products and services to our valued customers.
