SDEC Engine Series

Powered by SDEC diesel engine

Our SDEC engine series diesel generator sets incorporate cutting-edge technologies like turbocharging and intercooling, achieving exceptional performance in a compact design. These technologies enhance reliability, reduce emission and noise, and significantly better the operating environment of the diesel engines. Designed to fully satisfy user requirements for support and functionality, these generator sets are perfectly aligned with modern operational demands. Below are the specifications for our 360-500KW SDEC engine series diesel generator sets.

360kW/450kVA

Diesel Generator Set with SDEC Engine, DB-360GF

  • Prime power: 360kW/450kVA
  • Standby power: 396kW/495kVA
  • Rated current: 648A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai SC25G610D2
  • Alternator: Stamford/Leroy Somer/Engga (optional)

400kW/500kVA

Diesel Generator Set with SDEC Engine, DB-400GF

  • Prime power: 400kW/500kVA
  • Standby power: 440kW/550kVA
  • Rated current: 720A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai SC25G690D2
  • Alternator: Stamford/Leroy Somer/Engga (optional)

500kW/625kVA

Diesel Generator Set with SDEC Engine, DB-500GF

  • Prime power: 500kW/625kVA
  • Standby power: 550kW/688kVA
  • Rated current: 900A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai SC27G830D2
  • Alternator: Stamford/Leroy Somer/Engga (optional)
Speed: 1500rpmCylinders No. & Type: 12 cylinders, V line, 4 stroke, diesel engine, water-cooled
