Roof panel
Himin translucent roof panel is a new concept in solar roofing systems. It combines the main aspects of PV and roofing into one product, that is generating energy and weatherproofing. The panels are based on conventional tedlar backed PV panels however the panel edge extrusions are designed to interlink to provide a waterproof seal, thus the panel is the roof. The panels have a clear finish which creates a dappled lighting effect. The system includes condensation trays and vents.
With weatherproof seals between the panels, a mechanical flashing, and a condensate drain the Himin translucent roof panel can be used in place of any other roofing system, providing an elegant and reliable roofing solution.
BRE tested for wind uplift
- Wind uplift resistance tested in accordance with MCS 012: 3748.3Pa
BRE tested for fire resistance
- Fire resistance tested in accordance with MCS 012: BS476:Part 3:2004: Designation EXT.S.AA
Ensures daylight transmission
PV - 8% Clear Panel 80%, which can decrease the energy bill for lighting indoor.
With Himin translucent roof panel framing and the glazing system are already integrated. each panel comes complete and ready to install. No specialist tools required with each panel screwed into place using standard fixings (supplied)
-
Zhejiang Province Zhangwu Town Size: 81kw
Complete time: 2015 -
Lesotho: 50kw
Complete time: 2015 -
UK: 10kw
Complete time: 2012
