7A09 Aluminum Alloy
Request a Quote
Applications of 7A09 aluminum alloy
7A09 aluminum alloy is used for aircraft parts, gears and instrument shafts, missile parts, regulating vale parts, worm gears, aerospace/defense application, medical apparatus and instruments, precision mold, optical instruments, industrial robots, etc.
Aluminum alloy state, size and mechanical properties| Alloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
| Chinese standard | Value | ||||
| 7A09 | O | ＞0.50-10.0 | ≤245 | ≤245 | ≥11 |
| T6 | 0.50-2.90 | ≥480 | ≥480 | ≥7 | |
| ＞2.9-10.0 | ≥490 | ≥490 | ≥7 | ||
| T1 | ＞4.50-10.0 | ≥490 | ≥490 | ≥12 | |
| ＞10.0-12.5 | ≥14 | ||||
| ＞12.5-25.0 | ≥15 | ||||
| ＞25.0-40.0 | ≥14 | ||||
| F | ＞4.50-150.0 | - | - | ||
