APB 25-45 Ton High Speed Precision Metal Stamping Press
Request a Quote
- The metal stamping press is manufactured using strong steel casting. It features high precision, high rigidity and seismic resistance after heat treatment and eliminating the internal stress of the casting.
- The slide is on the long slide way to ensure the precision and stability of the stamping press during operation.
- The transmission parts of the stamping press adopt a centralized testing and automatic forced lubrication system, which can achieve real-time control and self-protection function.
- Sensitive and reliable clutch/brake, excellent double solenoid valve were used to ensure the precision and safety of the start and stop of slide.
- This precision high speed stamping press is designed with a complete electric circuit, meeting European standards.
- The punch is designed with a 3 point pivot system composed by guide post and plunger piston, which is useful for long-term precision operation.
- Touch screen not only makes it easy to set and operate, but also can display the fault information for quick and easy maintenance.
Item | Unit | |
Capacity | Ton | 25 |
Stroke | mm | 300 |
Die height | mm | 200 |
Stroke per minute | S.P.M | 0(200)-400 |
Slide adjustment | mm | 50 |
Slide area | mm | 300× 240× 50 |
Bolster area | mm | 530× 310× 70 |
Bed opening (LR×FB) | mm | 300× 160 |
Main motor | KW | 2.2 |
Max. weight of upper die | kg | 30 |
Presses dimension | mm | 1100× 760× 1800 |
Presses weight | ton | 1.8 |
Presses precision | GB(JIS) 1 class-J |
Item | Unit | |
Capacity | Ton | 45 |
Stroke | mm | 30 |
Die height | mm | 240 |
Stroke per minute | S.P.M | 0(200)-400 |
Slide adjustment | mm | 75 |
Slide area | mm | 460×340×70 |
Bolster area | mm | 720×460×80 |
Bed opening (LR×FB) | mm | 360×200 |
Main motor | KW | 55 |
Max. weight of upper die | kg | 150 |
Presses dimension | mm | 1700×1000×2400 |
Presses weight | ton | 3.7 |
Presses precision | GB(JIS) 1 class-J |
Standard Configuration
1. Sticking release device
2. Automatically-recirculating lubrication Device
3. Manual slide adjusting device
4. Electrical stroke counter
5. Programmable logical controller
6. Balance device
7. Rotary cam switch
8. Crank angle indicator
9. Air source receptacle
Optional Configuration
1. Air ejector
2. Auti-vibration press mount
3. Inverter
4. Die room light
5. Preset counter
6. Feeder
7. Misfeed detection consent
8. Electronic cam displayer
9. PAC 100 counter system
10. Human-machine counter system
