APE 160-400 Ton Precision Metal Stamping Press
Request a Quote
- APE series precision metal stamping press was developed and manufactured with a strong steel structure and welded using high quality steel plate. The metalworking machine tool features stable precision and reliability after eliminating the internal stress of the material.
- Two symmetrical balancers are used to ensure the stability of operation.
- The precision of die height adjustment is as high as 0.1 mm, so the stamping press can be operated safely, conveniently and reliably.
- The parts, like bent axle, gear systems, connecting rod, etc., have high integrality and abrasive resistance after hard-anodized and grinding process.
- Sensitive and reliable clutch/brake, excellent double solenoid valve and overload protector are used to ensure the precision and safety of the start and stopping of the slide.
- This straight side frame press features an integrative rack, which makes it suitable for processing precise progressive dies.
- The stamping press avoids the defect of C frame presses, reducing maintenance costs during the metalworking process.
- It features a high torque wet clutch, delivering long service life and low maintenance costs.
- The multifunctional electronic control system results in high operational safety.
| Specification | Model | ||
| Model | Ton | S | H |
| Rated tonnage point | mm | 6 | 3 |
| Stroke | mm | 180 | 130 |
| Stroke per minute | s.p.m | 30-55 | 40-85 |
| Die height | mm | 450 | 400 |
| Slide adjustment | mm | 100 | |
| Slide area | mm | 1600 × 650 | |
| Bolster area | mm | 1800 × 760 | |
| Side opening | mm | 700 × 450 | |
| Main motor | Kw | 15 | |
| Slide adjust device | Kw × P | 0.75× 4 | |
| Air pressure | kg/cm2 | 5 | |
| Presses precision | GB(JIS) 1 class | ||
| Specification | Model | ||
| Model | Ton | S | H |
| Rated tonnage point | mm | 6 | 3 |
| Stroke | mm | 250 | 150 |
| Stroke per minute | s.p.m | 20-50 | 35-70 |
| Die height | mm | 500 | 450 |
| Slide adjustment | mm | 120 | |
| Slide area | mm | 1850 × 750 | |
| Bolster area | mm | 2200 × 940 | |
| Side opening | mm | 900 × 600 | |
| Main motor | Kw | 18 | |
| Slide adjust device | Kw × P | 0.75× 4 | |
| Air pressure | kg/cm2 | 5 | |
| Presses precision | GB(JIS) 1 class | ||
| Specification | Model | ||
| Model | Ton | S | H |
| Rated tonnage point | mm | 7 | 3 |
| Stroke | mm | 280 | 170 |
| Stroke per minute | s.p.m | 20-40 | 30-60 |
| Die height | mm | 550 | 450 |
| Slide adjustment | mm | 120 | |
| Slide area | mm | 2100 × 900 | |
| Bolster area | mm | 2500 × 1000 | |
| Side opening | mm | 900 × 600 | |
| Main motor | Kw | 22 | |
| Slide adjust device | Kw × P | 1.5× 4 | |
| Air pressure | kg/cm2 | 5 | |
| Presses precision | GB(JIS) 1 class | ||
| Specification | Model | ||
| Model | Ton | S | H |
| Rated tonnage point | mm | 7 | 3 |
| Stroke | mm | 300 | 170 |
| Stroke per minute | s.p.m | 20-35 | 30-50 |
| Die height | mm | 550 | 450 |
| Slide adjustment | mm | 120 | |
| Slide area | mm | 2200 × 900 | |
| Bolster area | mm | 2500 × 1000 | |
| Side opening | mm | 900 × 600 | |
| Main motor | Kw | 30 | |
| Slide adjust device | Kw × P | 1.5 × 4 | |
| Air pressure | kg/cm2 | 5 | |
| Presses precision | GB(JIS) 1 class | ||
| Specification | Model | ||
| Model | Ton | S | H |
| Rated tonnage point | mm | 7 | |
| Stroke | mm | 300 | |
| Stroke per minute | s.p.m | 20-30 | |
| Die height | mm | 550 | |
| Slide adjustment | mm | 120 | |
| Slide area | mm | 3100 × 1000 | |
| Bolster area | mm | 3200 × 1000 | |
| Side opening | mm | 900 × 600 | |
| Main motor | Kw | 30 | |
| Slide adjust device | Kw × P | 1.5 × 4 | |
| Air pressure | kg/cm2 | 5 | |
| Presses precision | GB(JIS) 1 class | ||
| Standard | Optional |
| High performance dry clutch & brake | High performance wet clutch & brake |
| Standard operating system of kiston | Die cushion |
| Operation mode selection/off/inching | Vs motor |
| Safety one stroke /continuous | Touch screen devices |
| Hydraulic overload protector | Safety light curtain |
| Overrun detector | Slide knock-out device |
| Dual solenoid valve | Main motor reversing circuit |
| Missfeed detector | Foot switch |
| Motorized slide adjustment | Safety die block with plug |
| Digital die height indicator(unit 0.1mm) | Portable 2-hand push |
| Motorized grease pump | Inverter |
| Total counter,6 digits | Anti-vibration amounts |
| Preset counter,6 digits | Quick die change system |
| Maintenance counter,4 digits | Upper die clamper |
| Life counter ,6 digits | Lower die clamper |
| Electronic rotary cam switch(6 spare channel) | Die lifter |
| Air ejector 1/2" one channel | Die arm |
| Air source receptacle 1/2" two channel | Anchor bolts & foundation plates |
| Missfeed detection circuit | Automatic feed equipment |
| Power receptacle(available only for single phase 110V power source wiring by user) | NC straightener feed c/w uncoiler (3 in 1) |
| NC roller feeder | |
| Straightener c/w uncoiler (2 in 1) | |
| Straightener |
Capacity curve
