Hydraulic Coil Hot Press

Hydraulic coil hot press is used for fine size fixing and solidifying motor coils in large sizes, achieved by 6 auxiliary hydraulic oil cylinders, two sets expanding modules and imitate coil mould.

Main Features

• High precision constant temperature heating, presetting temperature, time and pressure
• Simple structure, convenient operation, center distance and angle can be adjusted freely
• Hydraulic clamping, more stable
• PLC control, HMI operation

Technical Data

• Machine modelWHD-1500 (customized)
• Applicable motor coil lengthMax. 1500mm
• Applicable motor coil span width220-900mm
• Applicable motor coil angle0~120°
• Applicable motor coil section7~30mm width x 20~70mm height
• Applicable motor coil weightMax. 200kg
• Working table overturning speed4.5~12 seconds
• Heating tube length1500mm
• Heating power15kW
• Heating temperatureMax. 200℃
• Hydraulic station motor power2.2kW
• Working cycle time5~15 minutes
• Angle fixing accuracy±0.5°
• Machine dimension2150 x 1200 x 1400mm
