Stationary TMR Mixer, 6 to 12m³
Single Auger TMR Mixer
The FS series stationary TMR mixer is designed for farms that need reliable daily ration mixing in a compact fixed setup. With capacities from 6 to 12 m³, or 211.89 to 423.78 ft³, this single-auger configuration is suitable for small to medium feeding batches where consistent mixing, lower power consumption, and simple operation matter.
At the center of the system is a vertical auger installed inside a cylindrical tub with a conical bottom. During operation, feed ingredients are lifted upward and then fall naturally back into the mixing chamber, creating a gentle but effective mixing cycle. This process helps reduce damage to feed fiber while supporting uniform distribution of roughage, concentrates, and additives.
For farms with limited space or specific feeding routines, optional accessories can be added to match different loading, discharge, weighing, and control requirements. Contact UHAND to configure the right fixed mixing setup for your ration volume, barn layout, and daily feeding workflow.
| FS Series Stationary Feed Mixer (Single Auger TMR Mixer) | ||||
| Model | ||||
| Dimensions (L×W×H) (mm) | 3410×2230×2340 | 3680×2230×2540 | 4170×2230×2710 | 4200×2250×3020 |
| Weight (kg) | 2400 | 2900 | 3500 | 3700 |
| Capacity (m³) | 6 | 8 | 10 | 12 |
| Motor Power (kW) | 15 | 22 | 37 | 30 |
| Motor Drive | VFD | VFD | VFD | VFD |
| Number of Augers | 1 | 1 | 1 | 1 |
| Auger Flighting Thickness (mm) | 20 | 20 | 20 | 20 |
| Auger Speed (r/min) | 33 | 33 | 34 | 34 |
| Number of Knives | 7 | 7 | 9 | 9 |
| Knife Material | 65Mn, tungsten carbide coated | 65Mn, tungsten carbide coated | 65Mn, tungsten carbide coated | 65Mn, tungsten carbide coated |
| Floor Thickness (mm) | 20 | 20 | 20 | 20 |
| Sidewall Thickness (mm) | 8 | 8 | 8 | 10 |
