WC 67Y Series Hydraulic Press Brake
This hydraulic press brake is normal numeric control, without CNC control system. The adjustment of backgauge and ram stroke is manual.
Features
- Steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
- Hydraulic top-drive, steadiness and reliability.
- Mechanical stop, steel torsion bar to maintain synchronization, high precision.
- Motorized-adjusting device of backgauge and rams stroke, adjusted by handwheel, numerical display.
- Deflection compensation unit is installed on the top die.
- For the machine size is more than 250ton, length 4000mm, it adopts manual crowned bottom die holder.
- The hydraulic press brake is guarded with safety interlocker.
WC 67K Series CNC Hydraulic Press Brake
Features
- Main machine selects WC67Y series press brakes.
- Equipped with CNC control system from ESTVN, DELEM or YBELEC.
- Equipped with world's famous hydraulic valves, oil pump, ball screw & linear rail, raster ruler, etc.
Technical Data
| Code | Nominal Pressure | Length of Worktable | Throat Depth | Ram Stroke | Number of Stroke | Motor Power | Weight | Overall Dimensions (L×W×H) |
| kN | mm | mm | mm | min-1 | kW | kg | mm | |
| 40/2200 | 400 | 2200 | 200 | 100 | 11 | 4 | 2800 | 2300×1300×1700 |
| 40/2500 | 400 | 2500 | 200 | 100 | 11 | 4 | 3200 | 2600×1300×1700 |
| 63/2500 | 630 | 2500 | 250 | 100 | 10 | 4 | 4800 | 2600×1400×2100 |
| 63/3200 | 630 | 3200 | 250 | 100 | 10 | 4 | 5500 | 3300×1400×2100 |
| 80/3200 | 800 | 3200 | 320 | 100 | 8 | 7.5 | 6100 | 3300×1450×2150 |
| 80/4000 | 800 | 4000 | 320 | 100 | 8 | 7.5 | 7000 | 4100×1450×2150 |
| 100/3200 | 1000 | 3200 | 320 | 120 | 8 | 7.5 | 7200 | 3300×1500×2200 |
| 100/4000 | 1000 | 4000 | 320 | 120 | 8 | 7.5 | 8500 | 4100×1500×2230 |
| 125/3200 | 1250 | 3200 | 320 | 120 | 8 | 7.5 | 7400 | 3300×1500×2260 |
| 125/4000 | 1250 | 4000 | 320 | 120 | 8 | 7.5 | 8800 | 4100×1500×2260 |
| 160/3200 | 1600 | 3200 | 400 | 200 | 8 | 11 | 10600 | 3300×1700×2400 |
| 160/4000 | 1600 | 4000 | 400 | 200 | 8 | 11 | 12800 | 4100×1700×2450 |
| 160/6000 | 1600 | 6000 | 400 | 120 | 7 | 15 | 17000 | 6200×1700×2550 |
| 200/3200 | 2000 | 3200 | 400 | 200 | 7 | 15 | 14000 | 3400×1800×2700 |
| 200/4000 | 2000 | 4000 | 400 | 200 | 7 | 15 | 17000 | 4200×1800×2750 |
| 200/6000 | 2000 | 6000 | 400 | 200 | 7 | 15 | 22000 | 6200×1800×3000 |
| 250/6000 | 2500 | 6000 | 400 | 200 | 7 | 18.5 | 30000 | 6200×1900×3100 |
| 300/6000 | 3000 | 6000 | 400 | 200 | 6 | 22 | 36000 | 6200×2000×3200 |
| 300/7000 | 3000 | 7000 | 400 | 200 | 6 | 22 | 40000 | 7200×2000×3400 |
| 400/7000 | 4000 | 7000 | 400 | 250 | 5 | 30 | 45000 | 7200×2100×3600 |
