Wheel Loader 996

The 996 wheel loader is equipped with a reliable original Cummins engine, ZF transmission case and torque converter. Also, it comes with original ZF wet-type axles with multi-disc limited-slip differentials. Its KD switch assures higher efficiency and easy operation. Its 24° cone-shaped seal cylinder comes with high sealing performance.

In addition, the front end loader comes with a single brake valve, dual pipe fully hydraulic brakes and central lubrication system.

Rated Load: 9000KG
Rated Output: 250kW
Rated Bucket Capacity: 5.1m³

Model	996
Length×Width×Height(mm)	9343×3200×3832
Rated load (Kg)	9000
Rated bucket capacity(m³)	5.1
Operating weight(Kg)	31500
Diesel engine	Original Cummins M11-C335
Rated output(KW)	250
Transmission case	ZF
Gear positions	4 forward gear, 3 reverse gear
Max. drawing force(KN)	269
Max. dump clearance(mm)	3325
Dump reach (mm)	1400
Wheel base(mm)	3650
Total cycle time (s)	11

1. Rated Load 2000Kg Rated Output 65kW Rated Bucket Capacity 1.0m³
1. Rated Load 3000Kg Rated Output 97/92kW Rated Bucket Capacity 1.7m³
1. Rated Load 4000Kg Rated Output 132kW Rated Bucket Capacity 2.3m³
1. Rated Load 5000Kg Rated Output 162kW Rated Bucket Capacity 3.1m³
1. Rated Load 5000Kg Rated Output 162kW Rated Bucket Capacity 3.1m³
1. Rated Load 5000Kg Rated Output 162kW Rated Bucket Capacity 3.1m³
1. Rated Load 5500Kg Travel Motor 200kW Rated Bucket Capacity 4.5m³
1. Rated Load 6000Kg Rated Output 174.5kW Rated Bucket Capacity 3.7m³
1. Rated Load 6000Kg Travel Motor 200kW Rated Bucket Capacity 4.5m³
1. Rated Load 7500Kg Rated Output 216kW Rated Bucket Capacity 4.2m³
1. Rated Load5000Kg Rated Output 162kW Rated Bucket Capacity 3.0m³
