GYFTY Non-metallic Aerial/Duct cable
Request a Quote
Optical Fiber & Fiber Patch Cables, Outdoor Self Supporting ADSS Cable
Product Details
- Cable type: GYFTY
- Application: Aerial/Duct Cable
- Standard: YD/T 901-2009
- Fiber count: 2~288，or as your request
- Fiber type: G652D, G657A1, or as requested
- Outer jacket: PE
- Packing: 2-4km/wooden drum
- Certification: ISO9001, ISO14001, OHSAS 18001, etc.
- Annual capacity: 45 million km
Customized Options
- Different fiber count
- Single mode and multimode fibers
- Desired sheath color
- Sheath in PE/LSZH
- Enhanced mechanical characteristics
- Enhanced tensile performance
- OEM service can be provided
Performance
- Low loss, low dispersion.
- Proper design and precise excess length control offer excellent mechanical and environmental properties to cable.
- Small size, light weight, self-supporting.
- Good electromagnetic interference resistance.
- LSZH flame retardant material is applied in sheath in the model GYFTZY.
- Applicable to access system, FTTH, CATV, computer network transmission system, etc.
Technical Specification
| Fiber Count | Cable Size (mm) | Cable Weight (kg/km) | Min. Bending Radius(mm) | Max. Tensile Load(N) | Max/ Crush Load(N/100mm) | |||
| Static | Dynamic | Short-term | Long-term | Short-term | Long-term | |||
| 2~36 | 10.3 | 90 | 10D | 20D | 1500 | 600 | 1000 | 300 |
| 38~72 | 11.3 | 117 | 10D | 20D | 1500 | 600 | 1000 | 300 |
| 74~96 | 12.8 | 158 | 10D | 20D | 1500 | 600 | 1000 | 300 |
| 98~120 | 14.4 | 191 | 10D | 20D | 1500 | 600 | 1000 | 300 |
| 122~144 | 15.9 | 221 | 10D | 20D | 1500 | 600 | 1000 | 300 |
| Operating Temperature | -40~70℃ | |||||||
Note: This data-sheet can only be a reference, but not a supplement to the contract.
Characteristics of the Fiber-G.652D
* PMDQ is a link of 20 cable sections (M) and a probability level of 0.01% (Q).
| Item | Specification | Item | Specification |
| Fiber Type | Single Mode | PMD | £0.2 ps/km1/2 |
| Fiber Material | Doped Silica | Mode Field Diameter @ 1310 nm | (8.6~9.5)±0.6 um |
| Attenuation Coefficient @ 1310 nm @ 1383 nm @ 1550 nm @ 1625 nm | £ 0.35 dB/km £ 0.35 dB/km £ 0.21 dB/km £ 0.30 dB/km | Chromatic Dispersion @ 1288 ~ 1339 nm @ 1271 ~ 1360 nm @ 1550 nm @ 1625 nm | £3.5 ps/(nm. km) £5.3 ps/(nm. km) £18 ps/(nm. km) £22 ps/(nm. km) |
| Point Discontinuity | £ 0.05 dB | Core / Clad Concentricity Error | £ 0.6 um |
| Cable Cut-off Wavelength | £ 1260 nm | Cladding Diameter | 125.0 ± 1 um |
| Zero-dispersion Wavelength | 1300 ~ 1324 nm | Zero-dispersion Slope | £ 0.092 ps/(nm2.km) |
| Primary Coating Diameter | 245 ± 10 um | Temperature Dependence 0oC~ 70oC @ 1310 & 1550nm | £ 0.1 dB/km |
| Proof test Level | 100 kpsi (=0.69 Gpa), 1% |
Please contact our sales people for more detailed information.
